KMD50CX

Classification: Diesel Clean Water Pump

Document download：

Please enter the password

OK Close

		2"	3"		4"	6"
Model No.		KMD50C	KMD80C		KMD100C	KMD150C
Water Pump	Inlet and Outlet Diameter	2 inch	3 inch	3 inch	4 inch	6 inch
	Maximum Head	30m	27m	29m	27m	25m
	Suction Head	8m	8m	8m	7m	7m
	Maximum Flow Rate	32m³/h	50m³/h	55m³/h	96m³/h	135m³/h
Engine	Power Model	KMD173F	KMD173F	KMD178F	KMD186FA	KMD192F
	Power Type Single-cylinder, vertical, air-cooled, 4-stroke, direct injection
	Displacement	247cc	247cc	296cc	418cc	498cc
	Power Output	5.0hp	5.0hp	5.5hp	9.0hp	11.0hp
	Starting Method	Recoil/Electric	Recoil/Electric	Recoil/Electric	Recoil/Electric	Recoil/Electric
	Fuel Tank Capacity	2.5L	2.5L	12L	12L	12L
	Oil Capacity	0.75L	0.75L	1.1L	1.65L	1.65L
Packaging Materials	Packaging Dimensions	5446.554cm	5446.554cm	5650.572cm	66.550.575.5cm	795783.7cm
	Net Weight/Gross Weight	32/37kg	37/42kg	48/52kg	76/81kg	98/102kg
	20GP/4OHQ	216/545	216/545	132/276	117/240	62/189
